ASUS ROG Strix 1000W Platinum

Overview

ROG STRIX 1000W PLATINUM (ROG EQUALIZER)

Superior Stability. Next-Level Efficiency The ROG Strix 1000W Platinum PSU delivers the top-tier performance and unwavering stability demanded by gamers. Featuring a next gen GaN MOSFET for premium power efficiency, it also incorporates the patented GPU-First Intelligent Voltage Stabilizer to maintain a steady and reliable flow of power to the graphics card. The ROG Strix 1000W Platinum further includes the ROG Equalizer, a patented 12V-2×6 PCIe power cable engineered to reduce heat stress and keep cable and connector temperatures well to protect the graphics card. With full ATX 3.1 compliance and a native 12V-2×6 connector, the ROG Strix Platinum Series ensures your high-end rig has the pow

GaN MOSFET

The ROG Strix Platinum PSU boasts an innovative GaN MOSFET that increases power efficiency by up to 30%, resulting in lower energy waste. Plus, the smaller size of a GaN MOSFET allows for a more organized internal layout. This optimized design provides space for larger heatsinks and enhanced airflow, improving heat dissipation within the PSU.

Patented GPU-First Intelligent Voltage Stabilizer (IVS)

Activate the GPU-First voltage sensing by connecting the GPU-First IVS cable. This innovative feature enhances voltage stability by up to 45%, even during demanding gaming sessions and overclocking scenarios. With this advanced technology, you can experience smooth and consistent gameplay. If you prefer conventional CPU-focused voltage sensing, simply disconnect the purple connector. Disclaimer: The GPU-First Intelligent Voltage Stabilizer is designed exclusively for 16-pin PCIe power cables. This feature is not available for 8-pin PCIe power cables.

ROG EQUALIZER

The ROG Equalizer is a soft embossed 12V-2×6 PCIe cable engineered to reduce heat stress and keep cable and connector temperatures well to protect the graphics card.

Reduced Cable Temperature

In demanding 600 W scenarios, uneven current distribution can cause hot spots in conventional 12 V-2×6 cables over long periods of use. ROG Equalizer helps balance power delivery to reduce thermal stress and maintain stable temperatures. Even under extreme conditions, it keeps cable and connector temperatures within the 105°C material limit for safer, more reliable operation. Test conditions : Ambient temperature: 55°C / Total Power: 600W The middle 4 wires of the +12 V cable disconnected to the graphics card 16pin

Enlarge Wire Load Capacity

Standard 12V-2×6 cables are rated for 9.2A per wire, while ROG Equalizer cables boost current capacity to 17A per wire. This is designed to improve the handling of short-term current peaks that may be produced by high-end graphics cards during extreme overclocking or when otherwise drawing a high amount of wattage from the power supply. This enhanced design improves durability under 600W continuous loads for a significantly longer lifespan than conventional cables, industry-leading reliability, and stable power delivery. *Recommended for use under a total power limit of 600W

Balanced Power Delivery

ROG Equalizer ensures balanced current delivery from PSU to ROG Equalizer, lowering graphics card connector temperatures and maintaining stable thermal performance below the 105°C material limit. Under an extreme test scenario, we removed the middle 4 wires from the +12V cable to simulate potential current imbalance conditions that may occur with a standard 12V-2×6 PCIe cable. Even under these conditions, the ROG Equalizer maintained a temperature of approximately 87.8°C. In contrast, a standard 12V-2×6 PCIe cable reached around 146°C—far exceeding safe operating limits. *Testing method: This extreme test removes the four middle wires of the +12V 16‑pin PCIe power cable to evaluate cable tem

80 PLUS and Cybenetics Platinum Efficiency Lambda A+ Noise Certification

The ROG Strix 1000W Platinum achieves 80 PLUS Platinum and Cybenetics Platinum certifications by leveraging low-ESR Japanese capacitors that deliver stability and efficiency, leading to improved power consumption, heat generation, acoustics and reliability. This model also earned a coveted Cybenetics Lambda A+ certification by emitting less than 20 dB of noise on average.

ROG Heatsinks

facilitate lower temperatures, longer component lifespan, and extended 0dB operation.

Dual-Ball Fan Bearings

Dual-ball bearings boast a remarkable lifespan of up to 80,000 hours, lasting up to twice as long as sleeve bearings and even exceeding fluid dynamic bearings. This helps ensure long-lasting, reliable cooling with minimal noise for the ROG Strix Platinum series.

Premium Copper Pins

Upgraded copper PCIe® connectors feature advanced thermal conductivity to help ensure cool operation and efficient power delivery. This translates to a significant 29% reduction in connector temperatures (up to 12.28°C), promoting optimal performance and stability for even the most demanding graphics cards.

0dB Technology

To reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 40% or below. *In 0dB mode (button pressed), the fan continues to spin when transitioning from high to low loads, ensuring safe temperatures are reached before stopping.
